The Canon XA70 Professional UHD 4K Camcorder is a compact, lightweight camera featuring UHD 4K capture, a 1" CMOS sensor, two XLR audio inputs, and one mini-HDMI output which fits right into the ENG category for documentary or journalism-style productions. Updated from its XA55 predecessor, this model features a larger 3.5mm LCD capacitive touchscreen display, a higher resolution tiltable 0.36" OLED EVF, OSD metadata recording, and fast USB Type-C video-only output with UVC support for livestreaming to a computer.

The lens optics include an integrated 15x HD optical zoom, a nine-bladed circular iris for more natural highlights, and wide DR gamma support for low-light recording. The camera's pro-style features include Dual-Pixel and Contrast autofocus, fast- and slow-motion recording, full manual control, optical and electronic image stabilization, a 3.5" touchscreen LCD, user-assignable buttons, infrared mode, and a DIG!C DV 6 image processor with high sensitivity and low noise. The XA70 also has display monitoring features such as zebra, color bars, and test tone, plus a built-in neutral density filter mechanism.

The camera records UHD 4K30 and Full HD 1080p60 captured to dual SD card slots in XF-AVC and MP4 formats, and it outputs to a mini-HDMI port. The dual SD card slots allow for automatic switching from one card to another, as well as simultaneous recording to both. The camera can output up to 1920 x 1080p 10-bit 4:2:2 video at 59.94 fps via its mini-HDMI output. On the audio side, the XA70 features up to four channels of LPCM audio with manual/automatic recording levels, two XLR inputs with phantom power, and a 3.5mm stereo mini input. It features a built-in stereo microphone as well as a headphone jack and a 2.5mm LANC input for control.

Compact Professional UHD 4K Camcorder
The XA70 captures sharp UHD images thanks to a 1" CMOS 4K sensor and DIGIC DV6 image processor. Oversampled HD delivers Full HD images from the 4K sensor.
On-Screen Display (OSD) "Time Stamp" Recording
OSD recording embeds date, time, timecode, and other data into your original camera files, effectively "time stamping" the information into each frame of video, a requirement for legal and law enforcement videographers.
UVC Livestreaming
Stream HD video directly from the camera via UVC1 to a Windows or macOS computer. Audio output through USB is not supported.
4K 15x Optical Zoom Lens
Adjustable focusing speeds and advanced Dual-Pixel CMOS AF give fast and precise focusing. Use the ultrabright 3.5" LCD to set focus by touching the AF point required. Face Detection AF and Face Tracking are available, while Manual Focus is set via the focus/zoom ring.
XF-AVC and MP4 for Flexible Recording
Choose from XF-AVC or MP4 recording formats. Record XF-AVC UHD 4K 160 Mb/s at 30P and Full HD 45 Mb/s at 60p/60i and 30/24p. For smaller files, record MP4 in 4K 150 Mb/s at 30/24p and Full HD 35 Mb/s or 17 Mb/s at 60/30/24p.
Professional Input and Output
Output options include HDMI, simultaneous backup and relay recording via dual SD cards, and Infrared mode. Record 5x slow motion in Full HD or Fast Motion in 4K/Full HD up to 1200x. Color match with other Canon cameras using the custom picture menu.
Professional Audio Options
Two XLR terminals on a detachable handle plus 4-channel linear PCM bring pro audio options.
Sensor Resolution
Actual: 13.4 Megapixel (4268 x 3148)
Effective: 8.29 Megapixel (3840 x 2160)
Image Sensor
1"-Type CMOS
Image Stabilization
Optical in Integrated Lens
Digital
Internal Recording Modes
H.264/MP4 4:2:0 8-Bit
3840 x 2160 at 23.98/24.00/29.97 fps
1920 x 1080p at 23.98/24.00/29.97/59.94 fps [35 to 45 Mb/s]
1280 x 720 at 59.94 fps [8 Mb/s]
XF-AVC 4:2:0 8-Bit
3840 x 2160 at 23.98/24.00/29.97 fps
1920 x 1080p at 23.98/24.00/29.97/59.94 fps
Show More
External Recording Modes
4:2:2 8-Bit via HDMI
1920 x 1080p at 23.98/29.97 fps
1920 x 1080i at 59.94 fps
1280 x 720 at 59.94 fps
4:2:2 10-Bit via HDMI
1920 x 1080p at 23.98/29.97/59.94 fps
1920 x 1080i at 59.94 fps
1280 x 720 at 59.94 fps
Show More
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-I)
Video I/O
1x Mini-HDMI 2.0 Output
Mobile App Compatible
No
Battery Type
Canon BP-8 Series
Imaging
Sensor Resolution
Actual: 13.4 Megapixel (4268 x 3148)
Effective: 8.29 Megapixel (3840 x 2160)
Image Sensor
1"-Type CMOS
Image Stabilization
Optical in Integrated Lens
Digital
Built-In ND Filter
Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Capture Type
Stills & Video
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
1/2000 to 1 Second
Minimum Illumination
1.7 Lux at 1/30 Shutter Speed
0.1 Lux at 1/2 Shutter Speed
White Balance
2000 to 15,000K
Lens
Focal Length
8.3 to 124.5mm (35mm Equivalent: 25.5 to 382.5mm)
Optical Zoom Ratio
15x
Max Digital Zoom
40x
Maximum Aperture
f/2.8 to 4.5
Minimum Focus Distance
Wide: 0.4" / 1.0 cm
Entire Zoom Range: 23.6" / 60.0 cm
Filter Size
58 mm
Focus Control
Autofocus
Manual Focus
Video Capture
Internal Recording Modes
H.264/MP4 4:2:0 8-Bit
3840 x 2160 at 23.98/24.00/29.97 fps
1920 x 1080p at 23.98/24.00/29.97/59.94 fps [35 to 45 Mb/s]
1280 x 720 at 59.94 fps [8 Mb/s]
XF-AVC 4:2:0 8-Bit
3840 x 2160 at 23.98/24.00/29.97 fps
1920 x 1080p at 23.98/24.00/29.97/59.94 fps
External Recording Modes
4:2:2 8-Bit via HDMI
1920 x 1080p at 23.98/29.97 fps
1920 x 1080i at 59.94 fps
1280 x 720 at 59.94 fps
4:2:2 10-Bit via HDMI
1920 x 1080p at 23.98/29.97/59.94 fps
1920 x 1080i at 59.94 fps
1280 x 720 at 59.94 fps
Fast-/Slow-Motion Support
Yes
Broadcast Output
NTSC
Built-In Microphone
Stereo
Audio Recording
MP4: 2-Channel 16-Bit AAC Audio
MP4: 4-Channel 16-Bit LPCM Audio
XAVC: 4-Channel 24-Bit LPCM Audio
IP Streaming
No
Still Image Capture
Image File Format
JPEG
Interface
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-I)
Video I/O
1x Mini-HDMI 2.0 Output
Audio I/O
2x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Input
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O
1x USB-C Input
Other I/O
1x USB-C Output
1x 2.5 mm Sub-Mini (LANC) Control Input
Wireless
No
Mobile App Compatible
No
Global Positioning (GPS, GLONASS, etc.)
No
Monitor
Display Type
Articulating Touchscreen LCD
Display Size
3.5"
Resolution
2,760,000 Dot
Viewfinder
Type
Built-In Electronic (LCD)
Size
0.36"
Resolution
1,770,000 Dot
Diopter Adjustment
-5.5 to +2
Focus
Focus Type
Auto and Manual Focus
Focus Mode
Automatic, Manual Focus
Environmental
Operating Temperature
32 to 72°F / 0 to 40°C (Recommended)
Storage Temperature
23 to 113°F / -5 to 45°C
Operating Humidity
85%
Storage Humidity
60%
General
Battery Type
Canon BP-8 Series
Power Consumption
5.3 W
Tripod Mounting Thread
1/4"-20 Female
Accessory Mounting Thread
No
Dimensions (W x H x D)
8.4 x 4.3 x 3.6" / 21.3 x 10.9 x 9.1 cm
Weight
2.2 lb / 985 g (Body Only)
3.2 lb / 1460 g (With Battery, Handle, Recording Media)
Packaging Info
Package Weight
5.825 lb
Box Dimensions (LxWxH)
14.8 x 11.8 x 9"
