OM SYSTEM OM-1 Mark II with 12-40mm f/2.8 Lens OM SYSTEM OM-1 Mark II with 12-40mm f/2.8 LensOM SYSTEM OM-1 Mark II with 12-40mm f/2.8 LensOM SYSTEM OM-1 Mark II with 12-40mm f/2.8 LensOM SYSTEM OM-1 Mark II with 12-40mm f/2.8 LensOM SYSTEM OM-1 Mark II with 12-40mm f/2.8 LensOM SYSTEM OM-1 Mark II with 12-40mm f/2.8 Lens
Olympus

OM SYSTEM OM-1 Mark II with 12-40mm f/2.8 Lens

SKU: 465742
MPN: V210041BU000
BRAND: Olympus
CONDITION: New

Extended Warranties Available:

Availability: In Stock
Fast & Free Shipping (Ships in 1-2 Business Days)
MSRP: $2,999.99
You Pay: $3,089.99




Need help? Call Us:
800-213-7037

Olympus Lenses

Memory & Digital Media

Bags & Cases

Micro Four Thirds Flagship
The first flagship to carry the OM SYSTEM name, the OM-1 Mark II is a revamped second iteration of the proven Micro Four Thirds mirrorless camera. Its 20MP stacked BSI Live MOS sensor and TruePic X processor deliver high-quality captures, speedy autofocus, and excellent low-light performance with a native ISO range of 200 to 102,400. Primed to give you a closer view of your subject due to the crop factor of the Micro Four Thirds system, the OM-1 Mark II excels in wildlife and nature photography. When you're shooting handheld, the sharpness of your images is greatly improved by the 5-axis in-body image stabilization. Altogether, the OM-1 Mark II provides users mobility, precision, and a reliable workhorse camera for image and video capturing.

Among the noteworthy upgrades of the OM-1 Mark II are enhanced AI subject detection for humans, live graduated neutral density filters, updated menu configuration, 14-bit raw output, and rubberized dials.
Cross Quad Pixel AF
1053 individual focus points are made available by the OM-1 Mark II's comprehensive Cross Quad Pixel autofocus system, allowing the camera to catch focus nearly anywhere on the sensor. With this design, the camera automatically detects subjects such as birds, humans, animals, cars, airplanes, and trains in order to keep them in focus and track their movements. This Cross Quad Pixel AF algorithm paired with the TruePic X processor promises a high-speed, reliable focusing performance.
Notable Mark II Upgrades
  • 20% increase in image stabilization and 8.5 EV stops of compensation
  • Rubberized dials for a more tactile feel
  • Menu button can be programmed to Delete, making it so you don't have to remove your left hand from your lens
  • Triple the amount of tones in your images with 14-bit raw output
  • Improved blackout-free sequential shooting
  • Vertical video support
  • Live GND8 and ND128 Filtering
  • Improved Human AI subject detection AF
Designed for the Elements
IP53 rated, the OM-1 Mark II offers superior weather protection and withstands some of the harshest conditions in the field. Its tough construction renders the camera freezeproof, dust and splash resistant, and operable at temperatures as low as 14°F.
Video Capabilities
DCI & UHD 4K video recording are supported at up to 60p and 10-bit 4:2:0 sampling. Full HD recording is possible at high-speed rates up to 240 fps for slow-motion playback.



Vertical video is now available, opening up more compositional options when shooting and saving you time in post production.


Live ND
Supporting up to ND128, this function digitally simulates the effects of an optical neutral density filter so you can create slow shutter speed effects in your images. With Live ND, you can see the effects through the viewfinder and on the LCD monitor.

Useful Features
5.76m-dot OLED electronic viewfinder for clear eye-level shooting



3.0" 1.62m-dot swivel touchscreen LCD to enable an incredible range of viewing capabilities while capturing

Dual UHS-II SD card slots for extended shooting situations

Focus stacking up to 15 shots, focus bracketing up to 999 shots

AI Subject Detection AF
  • Humans
  • Birds
  • Dogs
  • Cats
  • Cars
  • Motorcycles
  • Airplanes
  • Helicopters
  • Trains

OM SYSTEM M.Zuiko Digital ED 12-40mm f/2.8 PRO II Lens

Exceptional Image Quality Anywhere You Go
Offering superb optical performance and high-resolution results, the M.Zuiko Digital ED 12-40mm f/2.8 PRO II from OM SYSTEM gives you exceptional image quality anywhere you go. Compact and lightweight for maximum portability, this wide-to-portrait-length zoom is a 24-80mm equivalent lens for Micro Four Thirds mirrorless cameras. Its advanced optical design includes a variety of sophisticated elements that reduce both chromatic and spherical aberrations throughout the zoom range for notable clarity, sharpness, and color accuracy.



An excellent choice for content creators, the lens features a high-speed movie and still compatible autofocus system for fast, smooth, and silent focusing performance, and with a minimum focusing distance of just 7.9" you can get close-up shots whenever you desire. Safeguarding the lens is a reliable weather-sealed design to ensure the lens' performance in inclement and harsh conditions, and a fluorine lens coating provides additional protection from dust, water droplets, grease, and dirt.


Advanced Optical Design
  • The lens construction integrates two ED (extra-low dispersion) elements, two aspherical elements, one DSA (dual super aspherical) element, one EDA extra-low dispersion aspherical element, one HD element, and two HR (high-refractive index) elements into its design to minimize aberrations, distortion, and color fringing throughout the zoom range while also contributing to overall image sharpness, clarity, and color accuracy.
  • A ZERO (Zuiko extra-low reflection optical) coating minimizes lens flare and ghosting for improved contrast and color fidelity when working in strong lighting conditions.
  • Fluorine coating provides protection to the optical system and repels dust, water droplets, grease, and dirt, ensuring easy removal even when they adhere to the lens surface.
Versatile and Dependable Workhorse
  • Standard wide-angle to portrait-length zoom lens is designed for Micro Four Thirds mirrorless cameras and provides a 24-80mm equivalent focal length range.
  • Constant f/2.8 maximum aperture enables consistent low-light performance and selective focus control throughout the zoom range. Combined with a rounded seven-blade diaphragm, this produces a smooth bokeh quality beneficial to portraiture and close-up photography.
  • Movie and still compatible (MSC) autofocus system benefits both photo and video applications due to its smooth, quiet, and fast performance.
  • Reliable weather-sealed design ensures the lens's performance in inclement and harsh conditions.
Lens Mount
Micro Four Thirds
Sensor Resolution
Actual: 22.9 Megapixel
Effective: 20.4 Megapixel
Image Sensor
17.4 x 13 mm (Four Thirds) BSI MOS
Image Stabilization
Sensor-Shift, 5-Axis
ISO Sensitivity Range
Photo/Video
200 to 25,600 in Manual, Auto Mode (Extended: 80 to 102,400)
Continuous Shooting
Up to 120 fps
Internal Recording Modes
H.264/MPEG-4 AVC
4096 x 2160 at 23.98/25/29.97/50/59.94 fps [202 Mb/s]
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [202 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120/200/240 fps [202 Mb/s]
H.265
4096 x 2160 at 23.98/25/29.97/50/59.94 fps [152 Mb/s]
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [152 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120/200 fps [162 Mb/s]
Show More
External Recording Modes
4:2:2/Raw 8/12-Bit via HDMI
4096 x 2160
3840 x 2160
1920 x 1080
Show More
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-II)
Video I/O
1x Micro-HDMI (Unspecified Signal) Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O
1x USB-C Input/Output
Other I/O
1x USB-C Data Input/Output (Shared with Power Input)
1x PC Sync Socket
Wireless
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 4.2
Display Type
Articulating Touchscreen LCD
Battery Type
1x BLX-1 Rechargeable Lithium-Ion (Approx. 500 Shots)
Imaging
Lens Mount
Micro Four Thirds
Sensor Resolution
Actual: 22.9 Megapixel
Effective: 20.4 Megapixel
Image Sensor
17.4 x 13 mm (Four Thirds) BSI MOS
Sensor Crop (35mm Equivalent)
Crop Factor: 2x
Image Stabilization
Sensor-Shift, 5-Axis
Built-In ND Filter
No
Capture Type
Stills & Video
Exposure Control
Shutter Type
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
Shutter Speed
Mechanical Shutter
1/8000 to 60 Seconds
Electronic Shutter
1/32000 to 60 Seconds
Electronic Front Curtain Shutter
1/320 to 60 Seconds
Bulb/Time Mode
Bulb Mode, Time Mode
ISO Sensitivity Range
Photo/Video
200 to 25,600 in Manual, Auto Mode (Extended: 80 to 102,400)
Metering Method
Center-Weighted Average, Highlight, Multi-Zone, Spot
Precise Scan Rate Control
Yes
Exposure Modes
Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation
-5 to +5 EV (1/3, 1/2, 1 EV Steps)
Metering Range
-2 to 20 EV
White Balance
2000 to 14,000K
Presets: AWB, Custom, Flash, Fluorescent, Overcast, Shade, Sunlight, Tungsten, Underwater
Continuous Shooting
Up to 120 fps
Interval Recording
Yes
Still Image Capture
Image Sizes
4:3
50 MP (8160 x 6120) *Via In-Camera Pixel-Shift
25 MP (5760 x 4320) *Via In-Camera Pixel-Shift
20 MP (5184 x 3888)
Aspect Ratio
1:1, 3:2, 4:3, 16:9
Image File Format
JPEG, Raw
Bit Depth
12-Bit
Video Capture
Internal Recording Modes
H.264/MPEG-4 AVC
4096 x 2160 at 23.98/25/29.97/50/59.94 fps [202 Mb/s]
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [202 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120/200/240 fps [202 Mb/s]
H.265
4096 x 2160 at 23.98/25/29.97/50/59.94 fps [152 Mb/s]
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [152 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120/200 fps [162 Mb/s]
External Recording Modes
4:2:2/Raw 8/12-Bit via HDMI
4096 x 2160
3840 x 2160
1920 x 1080
Fast-/Slow-Motion Support
Slow-Motion Only
Gamma Curve
FLAT, HDR-HLG, OM-Log
Recording Limit
No
IP Streaming
No
Built-In Microphone
Stereo
Audio Recording
16-Bit 48 kHz LPCM Audio
Interface
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-II)
Video I/O
1x Micro-HDMI (Unspecified Signal) Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O
1x USB-C Input/Output
Other I/O
1x USB-C Data Input/Output (Shared with Power Input)
1x PC Sync Socket
Wireless
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 4.2
Mobile App Compatible
Yes: Android & iOS
App Name: OM Image Share
Functionality: Access Stored Files, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)
GPS
*Via Connected Smartphone
Monitor
Display Size
3"
Resolution
1,620,000 Dot
Display Type
Articulating Touchscreen LCD
Viewfinder
Type
Built-In Electronic (OLED)
Resolution
5,760,000 Dot
Eye Point
21 mm
Coverage
100%
Magnification
Approx. 1.48x
Diopter Adjustment
-4 to +2
Focus
Focus Type
Auto and Manual Focus
Focus Mode
Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points
Photo, Video
Phase Detection: 1053
Flash
Built-In Flash/Light
No
Flash Modes
Fill In, Manual, Off, Red-Eye Reduction, Slow Sync
Maximum Sync Speed
1/250 Second
Flash Compensation
-3 to +3 EV (1/3, 1/2, 1 EV Steps)
Dedicated Flash System
TTL
External Flash Connection
Shoe Mount, PC Terminal
Environmental
Operating Temperature
14 to 104°F / -10 to 40°C
Storage Temperature
-4 to 140°F / -20 to 60°C
Operating Humidity
30 to 90%
Storage Humidity
10 to 90%
General
Battery Type
1x BLX-1 Rechargeable Lithium-Ion (Approx. 500 Shots)
Shoe Mount
1x Hot Shoe
Tripod Mounting Thread
1x 1/4"-20 Female (Bottom)
Material of Construction
Magnesium Alloy
Dimensions (W x H x D)
5.3 x 3.6 x 2.9" / 134.8 x 91.6 x 72.7 mm
Weight
1.1 lb / 511 g (Body Only)
Packaging Info
Package Weight
3 lb
Box Dimensions (LxWxH)
7.5 x 7.5 x 5.75"

OM SYSTEM M.Zuiko Digital ED 12-40mm F/2.8 PRO II Lens Specs

Key Specs
Focal Length
12 to 40mm (35mm Equivalent: 24 to 80mm)
Maximum Aperture
f/2.8
Lens Mount
Micro Four Thirds
Lens Format Coverage
Micro Four Thirds
Focus Type
Autofocus
Image Stabilization
No
Filter Size
62 mm (Front)
Maximum Aperture
f/2.8
Minimum Aperture
f/22
Lens Mount
Micro Four Thirds
Lens Format Coverage
Micro Four Thirds
Angle of View
84° 30'
Minimum Focus Distance
7.9" / 20 cm
Maximum Magnification
0.3x
Optical Design
14 Elements in 9 Groups
Diaphragm Blades
7, Rounded
Focus Type
Autofocus
Image Stabilization
No
Filter Size
62 mm (Front)
Dimensions (ø x L)
2.8 x 3.3" / 70 x 84 mm
Weight
13.5 oz / 382 g
Packaging Info
Package Weight
1.42 lb
Box Dimensions (LxWxH)
8.5 x 4.6 x 4.6"
  • OM SYSTEM OM-1 Mark II Mirrorless Camera (Body Only)
  • OM SYSTEM CB-USB13 USB Connection Cable
  • OM SYSTEM BLX-1 Lithium-Ion Battery (7.2V, 2280mAh)
  • OM SYSTEM F-7AC USB-AC Adapter
  • Shoulder Strap
  • FL-LM3 Flash
  • OM SYSTEM M.Zuiko Digital ED 12-40mm f/2.8 PRO II Lens
  • Front Lens Cap
  • Rear Lens Cap
  • Lens Wrapping Cloth
  • LH-66D Lens Hood
  • Brand New Factory Fresh Import Model
